SMT Device Applicable Dimensions (Quad Flat
Packages, Gullwing Leads) C A
Outline Open Top Socket Dimensions H Outline Clamshell Socket Dimensions H
E E G G E 0.65mm
Pitch CL = Clamshell OT = Open Top Part Number Pitch Pin Count Body A x B IC Dimensions Tip-to-Tip C x D Parallel Clamp E 1/2 - IC height F Socket Dimensions G X H IC51-0484-652 0.65 48 6.0 x 9.0 7.4 x 8.8 7.0 34.0 x 34.5 CL IC234-0564-084 *
0.65 56 10.0 x 10.0 12.8 x 12.8
1.50
29.3 x 29.3 OT
IC51-0564-680
0.65 56 10.0 x 10.0 13.2 x 13.2 11.8
34.0 x 35.5
CL IC51-0644-1586
0.65 64 12.0 x 12.0 15.3 x 15.3 13.9
36.0 x 39.0
CL IC51-0644-1602
0.65 64 12.0 x 12.0 14.0 x 14.0 13.1
20.0 x 42.0
CL IC51-0684-734
0.65 68 10.0 x 14.0 13.2 x 17.2
11.8 x 15.8
37.0 x 41.0
CL IC51-0724-651
0.65 72 13.0 x 13.0 15.8 x 15.8 14.2
34.0 x 38.5
CL IC201-0804-005 *-*
0.65 80 14.0 x 20.0 17.9 x 23.9
1.22
32.9 x 38.9 OT
IC201-0804-012 *-* 0.65 80 14.0 x 14.0 17.2 x 23.9
0.92
29.2 x 32.2 OT
IC234-0804-019 *
0.65 80 13.95 x 13.95 16.8 x 16.8
1.35
32.2 x 32.2 OT
IC51-0804-711
0.65 80 14.0 x 14.0 17.2 x 17.2 15.6
37.0 x 41.0
CL IC51-0804-795
0.65 80 14.0 x 14.0 16.0 x 16.0 15.3
37.0 x 41.0
CL IC51-0804-956-2
0.65 80 14.0 x 14.0 17.2 x 17.2 16.4
34.0 x 42.5 CL IC201-1004-028 *
0.65 100 14.0 x 20.0 17.2 x 23.2
1.20
32.2 x 38.2 OT
IC201-1004-071 * 0.65 100 14.0 x 20.0 17.2 x 23.2
0.45
31.0 x 37.0 OT
IC201-1004-072 *
0.65 100 14.0 x 20.0 16.0 x 22.0
0.70
31.0 x 37.0 OT
IC201-1004-016 *-* 0.65 100 14.0 x 20.0 17.9 x 23.9 1.28
34.2 x 34.2
OT IC234-1004-008 * 0.65 100 14.0 x 20.0 18.15 x 24.15 1.33 32.2 x 32.2 OT
IC234-1004-009 *
0.65 100 14.0 x 20.0 18.15 x 24.15 1.33 32.2 x 32.2
OT IC234-1004-013 * 0.65 100 14.0 x 20.0 17.2 x 23.2 1.35 32.2 x 32.2 OT IC234-1004-014 *
0.65 100 14.0 x 20.0 16.0 x 22.0 0.67 32.2 x 32.2
OT IC234-1004-015 *
0.65 100 14.0 x 20.0 16.75 x 22.75 0.67 32.0 x 32.0 OT IC234-1004-033 *
0.65 100 14.0 x 20.0 17.9 x 23.9 1.33 32.2 x 32.2
OT IC402-1004-002*-**
0.65 100 14.0 x 20.0 16.0 x 22.0
29.8 x 23.8
CL IC51-1004-814-1
0.65 100 14.0 x 16.0 17.0 x 22.0
17.0 x 23.0
34.0 x 42.5
CL IC51-1004-814-2
0.65 100 14.0 x 20.0 17.2 x 23.2
16.4 x 22.4
34.0 x 42.5
CL IC51-1004-814-6
0.65 100 14.0 x 20.0
15.8 x 21.8
34.0 x 42.5
CL IC51-1004-814-7
0.65 100 14.0 x 20.0 17.2 x 23.2 16.4 x 22.4
34.0 x 42.5 CL
IC51-814.KS-12033
0.65 100 14.0 x 20.0
16.4 x 22.4
34.0 x 42.5
CL IC201-1004-050 *
0.65 100 14.0 x 20.0 16.0 x 22.0
0.75
31.0 x 37.0 OT
IC51-1124-1036-2 0.65 112 20.0 x 20.0 23.2 x 23.2 22.3
34.0 x 42.5
CL IC51-1124-1036-YED
0.65 112 20.0 x 20.0 22.0 x 22.0 21.0
34.0 x 42.5
CL IC234-1364-025 *
0.65 136 27.95 x 27.95 32.0 x 32.0
1.48
47.6 x 47.6 OT
IC217-1444-003 * 0.65 144 26.0 x 26.0 30.9 x 30.9
1.90
52.0 x 62.0 OT
IC51-1444-1014
0.65 144 28.0 x 28.0 30.0 x 30.0 30.4
44.0 x 57.0
CL IC51-1444-1014-3
0.65 144 28.0 x 28.0 30.0 x 30.0 30.4
44.0 x 57.0
CL IC201-1604-006 *-*
0.65 160 28.0 x 28.0 31.2 x 31.2
1.65
46.2 x 46.2 OT
IC234-1604-064 * 0.65 160 28.0 x 28.0 32.8 x 32.8
1.60
48.4 x 48.4 OT
IC234-1604-018 *
0.65 160 27.95 x 27.95 32.0 x 32.0
1.48
47.6 x 47.6 OT
IC234-1604-032 * 0.65 160 28.0 x 28.0 30.6 x 30.6
1.66
47.6 x 47.6 OT
IC51-1604-845-1
0.65 160 28.0 x 28.0 30.0 x 30.0 30.6
44.0 x 57.0
CL IC51-1604-845-2
0.65 160 28.0 x 28.0 31.6 x 31.6 30.6
44.0 x 57.0
CL IC51-1604-845-4
0.65 160 28.0 x 28.0 31.2 x 31.2 30.2
44.0 x 57.0
CL IC51-1604-845-8
0.65 160 28.0 x 28.0 31.2 x 31.2 30.2
44.0 x 57.0
CL IC51-1604-926
0.65 160 28.0 x 28.0 31.4 x 31.4 30.4
44.0 x 57.0
CL .. Test &
Burn-In SPECIFICATIONS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE – DIMENSIONS IN MILLIMETER
